Smart Lighting

  • HPF PWM Dimmable
  • LPF PWM Dimmable
  • Linear PWM Dimmable
  • High Voltage, Non-isolated Constant Voltage Control
  • Part No. RDsonBVdssPFWithout VCCDimming ModeOVPTopologyOTPMax. Power
    Vin=176V-265V
    Vout=72V    		Package
    MT7860 --0.9-PWM / AnalogYBuckY100WSOP-8
    MT7864 2Ω600V0.9-PWM / AnalogYBuckY18WSOP-8
    MT7865 2Ω600V0.9-PWM / AnalogYBuckY36WDIP-8
  • Part No. RDsonBVdssPFWithout
    VCC    		Dimming ModeOVPTopologyOTPMax. Power
    Vin=176V-265V
    Vout=72V    		Package
    MT9710B --0.5YFull Range Analog DimmingYBuckY100WSOP-8
    MT9712BS 5Ω500V0.5YFull Range Analog DimmingYBuckY24WSOP-8
    MT9712BD 5Ω500V0.5YFull Range Analog DimmingYBuckY36WDIP-7
    MT9713BD 3Ω500V0.5YFull Range Analog DimmingYBuckY50WDIP-7
    MT9714BS 3Ω500V0.5YFull Range Analog DimmingYBuckY50WSOP-8
    MT9714BD 2.5Ω500V0.5YFull Range Analog DimmingYBuckY60WDIP-7
  • Part No. BVdssApplicationOTPDimming ModeTopologyMax. Power Vin=90V-132V or
    Vin=200V-264V    		  Package
    MT7651L 500VOne LED String Linear150℃PWM→analog dimming, Full range dimming with no flickerLinear10WESOP-8
    MT7652L 500VTwo LED String Linear150℃PWM→analog dimming, Full range dimming with no flickerLinear10WESOP-8
    MT7651H 500VOne LED String Linear150℃PWM→analog dimming, Full range dimming with no flickerLinear10WESOP-8
    MT7652H 500VTwo LED Strings Linear150℃PWM→analog dimming, full range dimming with no flickerLinear10WESOP-8
    MT7656H 500VOne LED String Linear meets the New EU standard 150℃PWM→analog dimming, Full range dimming with no flickerLinear10WESOP-8
    MT7658H 500VTwo LED String Linear meets the New EU standard 150℃PWM→analog dimming, Full range dimming with no flickerLinear10WESSOP-10
    MT7665 500VI2C protocol 5-channel linear145℃I2C protocol analog dimming, full range dimming with no flickerLinear10WESOP-8
  • Part No. MOSConstant CurrentPulse CurrentOutput VoltageTopologyPackage
    MT8803R3 700V60mA120mA3.3VBuckSOT23-3
    MT8803T0 700V60mA120mA3.3V/5VBuckSOT23-5
    MT8813S0 700V60mA120mA3.3V/5VBuckSOP-8
